Cable Laying Products Fiberglass Conduit Duct Rodder
Basic Info
Model No.: FDR
Product Description
High Strong Duct Rodder/ Electric Cable Duct Rod
Duct Rodder widely use in telecom, electrical, wall and floor conduit, walker duct and utility installations.Fiberglass non-conductive, rust and corrosion resistant, superior pulling strength.
Duct Rodders combine ease of operation and reliable performance to help increase the efficiency of your rodding operations. The purpose of the duct rodder is to be able to accurately locate existing underground ducting or to locate the position of a blockage within a duct.
Fiberglass duct rodder consists of three parts: copper, glass fiber reinforced, high pressure low density polyethylene protective layer(smooth and strong, can be resistant to bad environment).Copper conductor article make fiberglass duct rodder can be easily placed in different ways.
Features of High Strong Duct Rodder/ Electric Cable Duct Rod
- Constructed of fiberglass reinforced in the center and consists of a rugged plastic layer that would ensure the lifetime of the flexible rod.
- Assembly: metal frame and rubber wheels, Wheel assembly for easy transportation; Guide rollers and the right parts for rotary coupling; parking brake for the flexible rod.
- There is copper wire inside for tracing easily.
- Polyethylene cover: Medium density polyethylene resin for the insulating and jacketing of cables.
- Rolling bearing cage flotation (reel transport) for mobility should be light and easy to use in the field, including a parking brake for the flexible rod.
- Feed device allows rod to feed out or be back with easy push or pull of rod
- Rugged tubular steel reel with adjustable positioning
- Rustproof bull-nose pulling eye for longer conduit run and underground duct
- Constructed of fiberglass reinforced in the center and consists of a rugged plastic layer that would ensure the lifetime of the flexible rod
Application
1.Used to install pulling ropes and winch ropes into ducts,ready for cable pulling operations.
2.Fiberglass rod is lightweight and flexible.
3.Dia of duct rod:4mm;6mm;8mm;9mm;10mm;11mm;12mm;13mm;14mm;15mm;16mm
4.Length of pulling rod:50m/100m/ 150m/ 200m/300m;
Technial Data of High Strong Duct Rodder/ Electric Cable Duct Rod
| Specification | Rod Diameter (mm) | Φ4,Φ4.5,Φ5,Φ6,Φ8,Φ10,Φ11,Φ12,Φ13,Φ14,Φ15,Φ16 |
| Rod Length (m) | 50~500 | |
| Frame Spec.(mm) | 1300x450x1330,1200x420x1220,980x350x1000,680x240x700, etc | |
| Wheel Diameter(mm) | 300mm | |
| Wall thickness of Metal Frame | 2.2mm | |
| Color | blue, yellow, red, white etc | |
| Material | Rod Inner | Extruded by fiber glass and high strength resin at high temperature |
| Rod Outer | High Density polyethylene coating | |
| Iron Frame | Steel with high-temperature sprayed plastic or Spray coating | |
| Wheel | rubber | |
| Brake | Yes | |
| Drawing head | copper | |
| Physical Characters | Density | 55g/m |
| Working temperature | -40°C to +80°C | |
| Breaking tension | 100kg | |
| Bending Radius | 295mm | |
| Technology | Pultrusion | |
| Packaging | Inside | plastic woven strip wind around the frame |
| Outside | Wooden pallet and Wooden box |
Fiberglass Duct Rodder Picture Show:
Fiberglass Duct Rodder Work Shop:
